Strong and versatile valve with flanged ends for easy installation. Delivers reliable sealing and smooth flow control. Designed for long-term industrial use. Ensures stability in tough conditions.
| GATE VALVE 150# | GATE VALVE 300# | GATE VALVE 600# | |||||||||||||||||
| SIZE | F/F | ØP | OD | FT | RF | PCD | N | F/F | OD | FT | RF | PCD | N | F/F | OD | FT | RF | PCD | N |
| 15MM | 108 | 13 | 89 | 9.6 | 34.9 | 60.39 | 4 | 140 | 95 | 12.7 | 34.9 | 66.5 | 4 | 165 | 95 | 14.2 | 34.9 | 66.5 | 4 |
| 20MM | 117 | 19 | 99 | 11.2 | 42.9 | 69.9 | 4 | 150 | 117 | 14.2 | 42.9 | 82.6 | 4 | 190 | 117 | 15.7 | 42.9 | 82.6 | 4 |
| 25MM | 127 | 25 | 108 | 12.7 | 50.8 | 46.4 | 4 | 165 | 124 | 15.7 | 50.8 | 88.9 | 4 | 216 | 124 | 17.5 | 50.8 | 88.9 | 4 |
| 40MM | 165 | 38 | 127 | 15.9 | 73 | 98.4 | 4 | 190 | 155 | 19 | 73 | 114.3 | 4 | 241 | 155 | 22.4 | 73 | 114.3 | 4 |
| 50MM | 178 | 50 | 152 | 17.5 | 92.1 | 120.7 | 4 | 216 | 165 | 20.6 | 92.1 | 127 | 8 | 292 | 165 | 25.4 | 92.1 | 127 | 8 |
| 65MM | 190 | 63 | 178 | 20.7 | 104.8 | 139.7 | 4 | 241 | 190 | 23.9 | 104.8 | 149.4 | 8 | 330 | 190 | 28.4 | 104.8 | 149.4 | 8 |
| 80MM | 203 | 76 | 190 | 22.3 | 127 | 152.4 | 4 | 282 | 210 | 26.9 | 127 | 168.1 | 8 | 356 | 210 | 31.8 | 127 | 168.1 | 8 |
| 100MM | 229 | 100 | 229 | 22.3 | 157.2 | 190.5 | 4 | 305 | 254 | 30.2 | 157.2 | 200.2 | 8 | 432 | 273 | 38.1 | 157.2 | 215.9 | 8 |
| 150MM | 267 | 150 | 279 | 23.9 | 215.9 | 241.3 | 8 | 403 | 318 | 35.1 | 215.9 | 269.7 | 12 | 559 | 356 | 47.8 | 215.9 | 292.1 | 12 |
| 200MM | 292 | 200 | 343 | 27 | 269.9 | 298.5 | 8 | 419 | 381 | 39.6 | 269.9 | 330.2 | 12 | 660 | 419 | 55.6 | 269.9 | 349.2 | 12 |
| 250MM | 330 | 250 | 406 | 28.6 | 323.8 | 362 | 12 | 457 | 444 | 46 | 323.8 | 387.4 | 16 | 787 | 508 | 63.5 | 323.8 | 431.8 | 16 |
| 300MM | 356 | 300 | 483 | 30.2 | 381 | 431.8 | 12 | 502 | 521 | 49.3 | 381 | 450.8 | 16 | 838 | 559 | 66.5 | 381 | 489 | 20 |
| GATE VALVE 900# | GATE VALVE 1500# | ||||||||||||
| F/F | ØP | OD | FT | RF | PCD | N | F/F | OD | FT | RF | PCD | N | |
| 50MM | 368 | 50 | 215 | 38.1 | 6.4 | 165.1 | 8 | 368 | 216 | 38.1 | 6.4 | 165.1 | 8 |
| 65MM | 419 | 63 | 245 | 41.3 | 6.4 | 190.5 | 8 | 419 | 244 | 41.1 | 6.4 | 190.5 | 8 |
| 80MM | 381 | 76 | 241 | 38.1 | 6.4 | 190.5 | 8 | 470 | 267 | 47.8 | 6.4 | 203.2 | 8 |
| 100MM | 457 | 100 | 292 | 44.4 | 6.4 | 235 | 8 | 546 | 311 | 53.8 | 6.4 | 241.3 | 8 |
| 150MM | 610 | 150 | 381 | 55.6 | 6.4 | 317.5 | 12 | 705 | 394 | 82.6 | 6.4 | 317.5 | 12 |
| 200MM | 737 | 200 | 470 | 63.5 | 6.4 | 393.7 | 12 | 832 | 483 | 91.9 | 6.4 | 393.7 | 12 |
| 250MM | 838 | 250 | 546 | 69.8 | 6.4 | 469.9 | 16 | 991 | 584 | 108 | 6.4 | 482.6 | 12 |
| 300MM | 965 | 300 | 610 | 79.4 | 6.4 | 533.4 | 20 | 1130 | 673 | 124 | 6.4 | 571.5 | 16 |
The Flanged Valve offers a simple yet highly effective solution for industrial piping systems. Its flanged ends allow for easy installation, secure connection, and convenient removal during maintenance. This valve is known for its excellent sealing capability, which reduces leakage risk and ensures safe operation.
Built with high-quality materials, the valve resists wear and corrosion, making it suitable for a wide range of industrial fluids. Its robust body structure enhances longevity, while the smooth internal design ensures consistent flow and reduced pressure loss.
Our globe valves offer precise flow control, reliable shut-off, and durable performance, making them ideal for demanding throttling and regulation applications across various industries.
Crafted from premium-grade materials, our valves are engineered for durability, high performance, and consistent operation in the most demanding conditions.
Our products strictly comply with international quality and safety standards, including ISO, PED, SIL, and UKCA, ensuring seamless performance across global markets.
Our workforce is a blend of skilled engineers, QC experts, and R&D professionals who bring innovation and technical depth to every product we build.
From Ball Valves to Butterfly Valves, we offer a complete portfolio of industrial valves in a variety of sizes, pressure classes, and materials — with custom configurations available.
We have more than 2 decades of expeience in precision engineering and flow control.
